Marshall Studio Vintage Compact 20W Combo

Whether you’re looking for warm blues tones or punchy leads, the Studio Vintage Combo has the same tones as the original 1959. Find your sound with the choice of high treble and normal voice or create your own blend between the two.

Keep the same great sound even at lower volumes, switch between 20W and 5W to suit your playing environment.

Designed and engineered in UK. Made in UK.

• Built in our UK factory
• All-valve
• 20W to 5W at the flick of a switch
• 10” Celestion V-type speaker
• Same warm blues tones as the original 1959
• FX loop

GENERAL
• Model: SV20C
• Range: Studio
• CHANNELS: 2, BRIDGEABLE
• TECHNOLOGY: VALVE

ELECTRONICS
• Output wattage: 20W (with power reduction option to 5W)
• OUTPUTS: SPEAKER OUTPUTS: 5 X 1/4" JACK SOCKETS (16Ω LOAD / 8Ω LOAD / 4Ω LOAD), DI (1/4" JACK)
• INPUTS: 4 X 1/4" JACK INSTRUMENT INPUTS (HIGH/LOW SENSITIVITY)
• Controls: NORMAL/LOUDNESS II, HIGH TREBLE/LOUDNESS I, TREBLE, MIDDLE, BASS, PRESENCE
• Effects: None
• Effects loop: YES, 1 X SERIES SWITCHABLE

SPEAKERS
• Speaker configuration: 1x10"
• Speaker model: Celestion VT-Junior (16Ω, 50W)
• Unit impedance: 16Ω

VALVES
• Preamp valves: 2 x ECC83, 1 x ECC83 (phase splitter)
• Power amp valves: 2 x EL34

PHYSICAL UNIT
• Weight: 15.9kg / 35 lbs
• Width: 500mm / 19.7"
• Height: 460mm / 18.1"
• Depth: 245mm / 9.6"
• Country of origin: Designed and engineered in UK. Made in UK.

INCLUDED IN THE BOX
• Detachable power cable included
