Manley Laboratories Langevin DVC Dual Vocal Combo Stereo Channel Strip Mic Preamp EQ Limiter
We respect your privacy and don't share your email with anybody.
Alert me if this item is restocked
We have cancelled your request.
The Langevin DVC (Dual Vocal Combo) is a dual-channel strip combining discrete microphone preamplification, passive shelving EQ, and electro-optical limiting in a streamlined 2U format. Featuring transformer-coupled inputs with hand-wound Manley transformers and an all-discrete transistor topology, the DVC delivers 50 dB of clean gain with defined midrange presence and natural clarity for professional recording applications.
Discrete amplification with transformer-coupled inputs
Designed as an accessible alternative to the Manley VOXBOX®, the DVC is built around an all-discrete transistor signal path. Each microphone preamplifier is coupled with a hand-wound Manley transformer, providing 50 dB of gain with rich harmonic content and exceptional transient response. The discrete topology ensures low noise and wide dynamic range across all input sources.
Essential tone-shaping with passive shelving EQ
Each channel provides simple yet effective shelving equalization for low and high frequencies. The low shelf offers selectable corner frequencies at 40 Hz or 80 Hz, while the high shelf operates at 8 kHz or 12 kHz, allowing precise adjustments to add presence and weight to any source. The passive EQ can be completely bypassed for an uncolored signal path when transparency is required.
Flexible routing with electro-optical limiting
The DVC features two channels of electro-optical gain reduction derived from the acclaimed Manley ELOP® topology. This design provides smooth, transparent limiting with musical response characteristics ideal for vocals and instruments. Independent preamp/EQ and limiter sections allow operation as four discrete processing blocks, making the DVC equally effective for tracking and mix-bus applications.
• Dual-channel mic preamp with integrated shelving EQ and limiter
• All-discrete signal path with hand-wound Manley input transformers
• Musical dynamics control with electro-optical limiting stages
• Versatile channel strip architecture for tracking and mixing
Dual Mono Mic Preamp with EQ Section
• Frequency Response: ±0 dB 10 Hz to 20 KHz
• <0.05% THD @ 1kHz
• S/N Ratio: 103dB
• Gain: 38 dB to 53 dB (adjustable)
• Mic Input Impedance: 2400 Ohm
• Mic Input XLR: BALANCED TRANSFORMER COUPLED
• DIRECT Input Impedance: 150K UNBALANCED 1/4"
• Output Impedance: 11 Ohm XLR; 6 Ohm 1/4" output
• Maximum Output: +31dBv (75 volts peak-to-peak)
• Input Sensitivity @ 1KHz (45 dB gain setting): 55 mV
Electro-Optical Limiter Section
• ALL-DISCRETE audio path
• Balanced XLR inputs & outputs
• Unbalanced 1/4" inputs & outputs
• Silent conductive plastic INPUT attenuators
• GAIN REDUCTION controls
• BYPASS switches
• Sifam VU METERS
• Meters switch to read OUTPUT or REDUCTION
• STEREO LINK switch
• <0.04% THD @1kHz
• Gain: -2 dB to 12 dB (adjustable)
General Information
• Unit is factory set for 100V, 120V or 220-240VAC operation for original destination country's mains voltage
• Operating Mains Voltage changeable with power transformer changeover switch and fuse value change
