Manley Laboratories Neo-Classic Monoblock Power Amplifier 500W
We respect your privacy and don't share your email with anybody.
Alert me if this item is restocked
We have cancelled your request.
The Manley Neo-Classic 500W Monoblock represents the pinnacle of push-pull vacuum tube power amplification, delivering 470 watts of continuous output for commanding control over demanding loudspeaker systems. Utilizing ten KT90EH output tubes per channel in a push-pull configuration, this monoblock combines exceptional power reserves with the tonal accuracy and dimensional imaging that characterize high-performance tube amplification. Hand-assembled in California with custom-wound Manley IRON® transformers, the Neo-Classic 500W provides both technical excellence and musical refinement.
Dual operating modes for distinct sonic characteristics
The Neo-Classic 500W offers selectable Triode and Ultra-Linear operating modes, each optimized for specific performance priorities. Triode mode delivers 200 watts with enhanced harmonic richness and three-dimensional soundstage depth characteristic of triode-connected output stages. Ultra-Linear mode provides 470 watts of output power with maximum dynamic capability, extended bass control, and the headroom required for complex orchestral passages and high-SPL reproduction. This mode flexibility enables precise matching to both musical material and loudspeaker requirements.
Advanced power supply architecture for dynamic authority
The amplifier's power supply employs high-capacity reservoir capacitors for instantaneous energy delivery during transient peaks and sustained low-frequency demands. This robust supply architecture ensures controlled bass response and dynamic impact across the full power bandwidth. Custom-wound Manley IRON® output transformers, continuously refined through in-house development, maintain wide bandwidth with low distortion while providing proper impedance matching and exceptional damping control throughout the audio spectrum.
Intelligent operation modes with accessible maintenance
The Neo-Classic 500W incorporates Soft-Start circuitry to minimize inrush current during power-up, extending component longevity and reducing mains stress. Ever-Warm standby mode maintains tubes at optimal operating temperature with minimal power consumption, ensuring the amplifier remains ready for immediate full-power operation. Bias adjustment controls and measurement points are conveniently accessed behind the front panel, simplifying routine tube maintenance and ensuring sustained performance over extended service intervals.
• 470W monoblock output from ten KT90EH vacuum tubes in push-pull configuration
• Switchable Triode (200W) and Ultra-Linear (470W) operating modes
• High-capacity power supply delivering exceptional dynamic response and bass authority
• Balanced XLR and unbalanced RCA inputs with Manley IRON® input transformer
• Full Power (UL): 470 W @ 1.5% THD into 5 Ohms
• Full Power (Triode): 200 W @ 1.5% THD into 5 Ohms
• Output Tubes: 10 x KT90EH (per monoblock)
• Frequency Response: 10 Hz - 30 kHz (Triode, -1 dB)
• Dynamic Range: 110 dB A-WGT
• Inputs: Balanced XLR (Transformer) & Unbalanced RCA
